kubernetes

#列出所有支持的API资源
kubectl api-resources
#查看集群信息
kubectl cluster-info

#列出所有节点
kubectl get nodes
#列出所有命名空间
kubectl get namespaces
#创建命名空间
kubectl create namespace my-namespace

#查看集群的所有资源
kubectl get all --all-namespaces
kubectl get pods --all-namespaces
kubectl get pods --all-namespaces -o wide
kubectl get pods -n <namespace>
#查看系统pods
kubectl get pods -n kube-system

#查看 pod 的日志
kubectl logs -n <namespace> <pod-name>
kubectl logs -n kube-system pod/kube-proxy-www59
#查看前一个容器的日志，对于调试崩溃或重启的容器特别有用。
kubectl logs -n <namespace> <pod-name> --previous

#查看详细信息
kubectl describe node
kubectl describe service
kubectl describe pod -n <namespace> <pod-name>

#创建、删除资源
kubectl apply -f <file.yaml>
kubectl delete -f <file.yaml>

# 执行命令进入到某个 pod 的容器中
kubectl exec -it <pod-name> -n <namespace> -- /bin/bash
# 编辑 kube-proxy 配置
kubectl edit configmap kube-proxy -n kube-system

#重启pod
kubectl delete pod -n <namespace> <pod-name>
kubectl delete pods -n kube-system -l k8s-app=kube-proxy
kubectl delete pods -n kube-flannel -l k8s-app=flannel
kubectl -n kube-system rollout restart deployment coredns

#使用定时任务模版创建任务
kubectl create job --from=cronjob/test test-1 -n namespace

#flannel网络插件
kubectl get pod -n kube-flannel -l app=flannel
kubectl get daemonset -n kube-flannel kube-flannel-ds
kubectl edit configmap kube-flannel-cfg -n kube-flannel
kubectl delete pod -l app=flannel -n kube-flannel

#服务
kubectl get svc --all-namespaces
kubectl describe service openldap -n kubesphere-system
kubectl edit service openldap -n kubesphere-system
kubectl delete service openldap -n kubesphere-system

#工作负载
kubectl get deployments --all-namespaces
kubectl describe deployment nginx-deployment
kubectl set image deployment/nginx-deployment nginx=nginx:1.19
kubectl rollout undo deployment/nginx-deployment
kubectl scale deployment/nginx-deployment --replicas=5
kubectl delete deployment nginx-deployment

#重启
kubectl rollout restart deployment ks-apiserver -n kubesphere-system

#启动和停止
sudo systemctl start containerd
sudo systemctl stop containerd
sudo systemctl status containerd
#查看日志
journalctl -u containerd

#容器管理
ctr containers list
ctr container info <container-id>

#容器操作
ctr container create <image> <container-id>
ctr run <options> <image> <container-id> <command> [<args>...]
ctr task start <container-id>
ctr task status <container-id>
ctr task kill <container-id>
ctr container delete <container-id>

#镜像管理
ctr images list
ctr images pull <image-name>
ctr images remove <image-name>
ctr images info <image-name>

#运行容器
ctr run <options> <image> <container-id> <command>
ctr run --tty --rm alpine:latest mycontainer /bin/sh

#列出正在运行的容器
sudo crictl ps

#列出所有容器（包括已停止的容器）
sudo crictl ps -a

#查看容器详细信息
sudo crictl inspect <容器ID>

#列出所有镜像
sudo crictl images

#查看镜像详细信息
sudo crictl inspecti <镜像ID或名称>

#删除容器
sudo crictl rm <容器ID>

#拉取镜像
sudo crictl pull <镜像名称>

#删除镜像
sudo crictl rmi <镜像ID或名称>

#查看容器日志
sudo crictl logs <容器ID>

#启动容器
sudo crictl start <容器ID>

#停止容器
sudo crictl stop <容器ID>

#运行一个交互式 shell
sudo crictl exec -it <容器ID> sh

#启用IP转发
echo "net.ipv4.ip_forward = 1" >> /etc/sysctl.conf
echo "net.ipv6.conf.all.forwarding = 1" >> /etc/sysctl.conf
echo "net.bridge.bridge-nf-call-iptables = 1" >> /etc/sysctl.conf
sysctl -p

#内核模块，calico依赖
sudo modprobe ip_tables ipip nf_conntrack ip6_tunnel tun br_netfilter

#初始化控制节点
sudo kubeadm init --pod-network-cidr=10.244.0.0/16

#配置文件
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

#安装网络插件calico，性能好，功能强大
kubectl apply -f https://docs.projectcalico.org/manifests/calico.yaml
#或者安装网络插件flannel，简单适合初学者，依赖少，大多数环境都能跑起来，默认网段10.244.0.0/16
kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml

#移除控制节点标签，使其同时作为工作节点（分布式集群不推荐）
kubectl taint nodes --all node-role.kubernetes.io/control-plane-

#设置存储（配置文件见 存储 章节）
kubectl apply -f storageclass.yaml
#设置默认存储
kubectl patch storageclass hostpath -p '{"metadata": {"annotations": {"storageclass.kubernetes.io/is-default-class": "true"}}}'

# 重置，危险！
sudo kubeadm reset -f

#生成加入命令（控制节点）
kubeadm token create --print-join-command

#加入集群（工作节点）
kubeadm join <control-plane-endpoint> --token <token> --discovery-token-ca-cert-hash <hash>

#删除工作节点（控制节点）
kubectl delete node <节点名>

apiVersion: apps/v1
kind: Deployment
metadata:
name: nginx-deployment
spec:
replicas: 3
selector:
  matchLabels:
    app: nginx
template:
  metadata:
    labels:
      app: nginx
  spec:
    containers:
      - name: nginx
        image: nginx:1.14.2
        ports:
          - containerPort: 80

apiVersion: apps/v1
kind: ReplicaSet
metadata:
  name: nginx-replicaset
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
        - name: nginx
          image: nginx:1.14.2
          ports:
            - containerPort: 80

apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: web
spec:
  serviceName: "nginx"
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
        - name: nginx
          image: nginx:1.14.2
          ports:
            - containerPort: 80

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: fluentd
spec:
  selector:
    matchLabels:
      name: fluentd
  template:
    metadata:
      labels:
        name: fluentd
    spec:
      containers:
        - name: fluentd
          image: fluentd:v1.2.0

apiVersion: batch/v1
kind: Job
metadata:
  name: pi
spec:
  template:
    spec:
      containers:
        - name: pi
          image: perl
          command: [ "perl",  "-Mbignum=bpi", "-wle", "print bpi(2000)" ]
      restartPolicy: Never

apiVersion: batch/v1
kind: CronJob
metadata:
  name: hello
spec:
  schedule: "*/1 * * * *"
  jobTemplate:
    spec:
      template:
        spec:
          containers:
            - name: hello
              image: busybox
              args:
                - /bin/sh
                - -c
                - date; echo Hello from the Kubernetes cluster
          restartPolicy: OnFailure

apiVersion: autoscaling/v1
kind: HorizontalPodAutoscaler
metadata:
  name: nginx-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: nginx-deployment
  minReplicas: 1
  maxReplicas: 10
  targetCPUUtilizationPercentage: 50

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: hostpath
  labels:
    storage.kubesphere.io/storagetype: FileStorage
  annotations:
    storageclass.kubernetes.io/is-default-class: 'true'
provisioner: kubernetes.io/no-provisioner
reclaimPolicy: Delete
volumeBindingMode: WaitForFirstConsumer

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: aws-ebs
  annotations:
    storageclass.kubernetes.io/is-default-class: "true"
provisioner: ebs.csi.aws.com
parameters:
  type: aws-ebs
volumeBindingMode: WaitForFirstConsumer

apiVersion: v1
kind: PersistentVolume
metadata:
  name: host
  finalizers:
    - kubernetes.io/pv-protection
spec:
  capacity:
    storage: 50Gi
  hostPath:
    path: /app/k8s
    type: ''
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: hostpath
  volumeMode: Filesystem

apiVersion: v1
kind: PersistentVolume
metadata:
  name: aws-ebs
spec:
  capacity:
    storage: 20Gi
  accessModes:
    - ReadWriteOnce
  storageClassName: aws-ebs
  hostPath:
    path: /app/k8s_pv

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pvc-example
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi
  storageClassName: aws-ebs

# 查看存储类
kubectl get sc
# 删除存储类
kubectl delete sc aws-ebs
# 查看持久卷
kubectl get pv
kubectl delete pv aws-ebs
# 查看持久卷声明
kubectl get pvc
kubectl delete pvc aws-ebs

# 如果没有helm，安装
brew install helm

# 如果无法访问 charts.kubesphere.io, 可将 charts.kubesphere.io 替换为 charts.kubesphere.com.cn
helm upgrade --install -n kubesphere-system --create-namespace ks-core https://charts.kubesphere.io/main/ks-core-1.1.4.tgz --debug --wait
# 如果访问 Docker Hub 受限，请在命令后添加如下配置，修改默认的镜像拉取地址。
--set global.imageRegistry=swr.cn-southwest-2.myhuaweicloud.com/ks
--set extension.imageRegistry=swr.cn-southwest-2.myhuaweicloud.com/ks

# 卸载，危险！
helm -n kubesphere-system uninstall ks-core

# 如果没有helm，安装
brew install helm

# 添加 KubeSphere 的 Helm 仓库
helm repo add kubesphere https://charts.kubesphere.io/main
helm repo update

# 安装 KubeSphere
helm install kubesphere kubesphere/ks-installer --namespace kubesphere-system --create-namespace

# 自定义安装 KubeSphere，修改 values.yaml 文件中的配置
helm show values kubesphere/ks-installer > values.yaml
helm install kubesphere kubesphere/ks-installer --namespace kubesphere-system --create-namespace -f values.yaml

#创建用户名和密码
sudo yum install httpd-tools
mkdir -p /root/auth
htpasswd -Bc /root/auth/htpasswd default

#将 htpasswd 文件创建为 Kubernetes Secret
kubectl create secret generic registry-auth-secret --from-file=/root/auth/htpasswd -n registry

#将配置文件创建为 Kubernetes ConfigMap
kubectl create configmap registry-config --from-file=config.yml -n registry

#为了更好地管理资源，创建专用 Namespace（可选）
kubectl create namespace registry

#Deployment 会启动一个包含 Docker Registry 的容器，并将容器的端口 5000 暴露出来
#Service 将 Deployment 中的容器端口 5000 暴露为一个 ClusterIP 服务，使集群内部的其他容器可以访问这个 Docker Registry。
kubectl apply -f registry-deployment.yaml
kubectl apply -f registry-service.yaml

# 为了将镜像推送到 Kubernetes 内部的 Docker Registry，需要将 Docker 客户端配置为信任这个私有仓库。
# 可以通过 Kubernetes 集群节点的 IP 地址和 NodePort（例如 32000）访问 Docker Registry。
# 集群内部的其他容器可以直接通过 http://registry.registry:5000 访问 Docker Registry。
kubectl apply -f registry-nodeport.yaml

version: 0.1
log:
  fields:
    service: registry
storage:
  filesystem:
    rootdirectory: /var/lib/registry
http:
  addr: :5000
  secret: registry-auth-secret
  headers:
    X-Content-Type-Options: [ nosniff ]
  auth:
    htpasswd:
      realm: basic-realm
      path: /auth/htpasswd

apiVersion: apps/v1
kind: Deployment
metadata:
  name: registry
  namespace: registry
spec:
  replicas: 1
  selector:
    matchLabels:
      app: registry
  template:
    metadata:
      labels:
        app: registry
    spec:
      containers:
        - name: registry
          image: registry:2
          ports:
            - containerPort: 5000
          volumeMounts:
            - name: registry-storage
              mountPath: /var/lib/registry
            - name: registry-auth
              mountPath: /root/auth
            - name: registry-config
              mountPath: /etc/docker/registry
      volumes:
        - name: registry-storage
          emptyDir: { }
        - name: registry-auth
          secret:
            secretName: registry-auth-secret
        - name: registry-config
          configMap:
            name: registry-config

apiVersion: v1
kind: Service
metadata:
  name: registry
  namespace: registry
spec:
  selector:
    app: registry
  ports:
    - protocol: TCP
      port: 5000
      targetPort: 5000

apiVersion: v1
kind: Service
metadata:
  name: registry-nodeport
  namespace: registry
spec:
  type: NodePort
  selector:
    app: registry
  ports:
    - protocol: TCP
      port: 5000
      targetPort: 5000
      nodePort: 32000
